QCN9074 Wallys WiFi 6 (802.11ax) 4×4 MU-MIMO 2.4GHz /IPQ8074A 4x4 2.4G 8x8 5G 802.11ax

MT7915/MT7975/IPQ6000/IPQ6018/IPQ6010/IPQ4019/IPQ4029/ipq4018/IPQ4028/IPQ8072/IPQ8072A/IPQ8074/IPQ8074A/IQCN6024/QCN9074/QCN9072/QCN9024/IPQ5018/AR9223/QCA9880/QCA9882 /AR9582/AR9531/AR9344 /AX200NGW

With over 15 years of experience in wireless industry and penetrating market olfaction, Wallys has designed and manufactured many high quality and cost-effective routerboards and wireless network cards.


In the complex market, Wallys products stand out and are affirmed by partners. From 802.11 a - ax, Wallys always keeps up with the most cutting-edge wireless technology, aimed to help customers take the preemptive opportunities to occupy the market and lead a win-win cooperation.

BY:Wallys Communications (Suzhou ) Co., LTD

EMAIL:sales3@wallystech.com


DR8074A(HK01)


https://www.wallystech.com/Routerboard/DR8074A-HK01-wifi6-Qualcomm-IPQ8074A-4T4R-2-4GHz-and-8T8R-5GHz-support-OpenWRT-802.11AX-MU-MIMO-OFDMA.html


2x(4×4 or 8×8) 11AX MU-MIMO DUAL CONCURRENT EMBEDDEDBOARD

Features

  • Qualcomm Atheros IPQ8074A AR Quad Core CPU

  • On-board 5GHz radio, up to 4804Mbps physical data rate 32MB NOR Flash, 256MB NAND Flash

  • On-board 2.4GHz radio, up to 1147Mbps physical data rate

  • Support 11ax TX Beamforming

  • Support 11ac/ax MU-MIMO DL and UL

  • Support OFDMA DL and UL

  • Tri-band support with 5G SBS (4×4/5GHz + 4×4/5GHz) + 4×4/2.4GHz

  • Supports Dynamic Frequency Selection (DFS)

Applications

  • Dual Band MU-MIMO 802.11g/n/ac/ax

  • Access Point Wireless application

  • 8×8 MU-MIMO 802.11ac Access Point

Product Description

524wifi 8074A(HK01) based on IPQ8074A chipset is an enterprise wireless module integrated with
2×2 5G high power Radio module and 2×2 2.4G high power Radio module designed
specifically to provide users with mobile access to high-bandwidth video streaming, voice, and
data transmission for office and challenging RF environment in factories, warehouses
establishment.

Absolute Maximum Rating

ParameterRatingUnitOperating Temperature Range-20 to 70ºCStorage Temperature Range-40 to 90ºCOperating Humidity Range5 to +95 (non-condensing)%Storage Humidity Range0 to +90 (non-condensing)%

Hardware Specifications

SymbolParameterCPUQualcomm Atheros Quad Core ARM Cortex 64-bit A53 Processor
IPQ8074A 2.2GHz CPUCPU FrequencyDerived from Qualcomm Atheros AP.HK01System Memory1GB (2x 512MB) DDR3L 32-bit interfaceFrequency Range2.412GHz to 2.472GHz, 5.150GHz to 5.825GHzModulation TechniquesOFDMA: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAMNGFF Slot for 5G ModuleM.2 (NGFF) “B Key” Socket with PCIe 3.0 interfaceOptional Onboard
ModulesSupports 1x BT module, 1x ZigBee module, 1x Touch pad
connector, 1x Audio header, 1x
LCD display headerFlashNOR Flash: 32MB
NAND Flash: 256MB
eMMC: 8GBWirelessOn-board 4×4 2.4GHz MU-MIMO 802.11b/g/n/ax, max TBDdBm per
chain
On-board 2x(4×4) or 8×8 5GHz MU-MIMO 802.11a/n/ac/ax, max
TBDdBm per chain
12x U.FL connectorsReset Buttons2x Hardware reset button, 1x WPS reset buttonDC Jack Input1x DC Jack Connector: 12V, 5AInterface5x Gigabit Ethernet (1GbE) LAN/WAN RJ45 Port (Auto MDI-X)
1x 10Gigabit Ethernet (10GbE) LAN/WAN RJ45 Port (Auto MDI-X)
1x SFP+ Port
2x USB 3.0 Port
1x Serial Port 12 Pin Connector
1x JTAG 20 Pin Connector
1x Buzzer
1x micro SD Card Socket
1x MiniPCIe Slot with PCIe 2.0LED13x LED indicators, 2 additional LED on Ethernet portPower ConsumptionTBD


DR9074-2.4G(PN01.1)


https://www.wallystech.com/Network_Card/DR9074-2.4G-PN01.1-Wifi-6-Qualcomm-QCN9074-Single-Band-2.4-GHz-4T4R-M.2-E-Key-Interface-802.11ax.html

WiFi 6 (802.11ax) 4×4 MU-MIMO 2.4GHz QCN9074 Single Band Wireless Module

Features

  • Qualcomm Atheros QCN9074

  • 2.4GHz, max 23dBm per chain

  • Single Band 2.4GHz 4×4 WiFi 6 (802.11ax)

  • 4 spatial streams (4SS)

  • M.2 E Key Interface

  • PCI Express 3.0 Interface

  • Supports Dynamic Frequency Selection (DFS)

Applications

  • Security Surveillance

  • Commercial radio coverage

  • Hotel Wireless application

  • Country coverage

  • Forest fire protection engineering

  • Some special scene application

Product Description

524wifi 9074-2.4G (PN01.1) based on IPQ9074 Chipset is an enterprise wireless module
integrated with 4×4 MU-MIMO 2.4GHz Single Band Wireless Module designed specifically to
provide users with mobile access to high-bandwidth video streaming, voice, and data
transmission for office and challenging RF environment in factories, warehouses
establishment.

Absolute Maximum Rating

ParameterRatingUnitOperating Temperature Range-20 to 70ºCStorage Temperature Range-40 to 90ºCOperating Humidity Range5 to +95 (non-condensing)%Storage Humidity Range0 to +90 (non-condensing)%

Hardware Specifications

SymbolParameterChipsetQualcomm Atheros QCN9074WLAN Host InterfacePCI Express 3.0 InterfaceSystem Memory2Mbit serial I²C bus EEPROMStandard Operating Voltage5VOperating SystemsOpenWRTHost InterfaceM.2 E KeyAntenna Cable / Port4xU.FL Connectors,4T4RFrequency Range2.412GHz-2.472GHzData Rates for WALN2.4GHz, max 23dBm per chain, up to 4949MbpsChannel Spectrum Widths
for WLANSupport 20/40MHz at 2.4GHzModulation TechniquesOFDMA: BPSK, QPSK, DBPSK, DQPSK,16-QAM, 64-QAM, 256-QAM,1024-QAMTemperature RangeOperating: -20°C to 70°C, Storage: -40°C to 90°CHumidityOperating: 5% to 95% (non-condensing), Storage: Max. 90% (non-condensing)CertificationTBDPower ConsumptionTBDReference DesignPN01.1Dimensions (WxHxD)57mm x 60mm x 3.2mm
