QCN9074 WiFi Card IPQ6010,802.11ax,2x2 2.4G&5G,
QCN9074 802.11ax 4x4 MU-MIMO 6GHz wifi6E
QCN9074 11ax 4x4 6G M.2
1.DR9074-6E(PN02.7)
Absolute Maximum Rating
Parameter
Rating
Unit
Operating Temperature Range
-20 to 70
ºC
Storage Temperature Range
-40 to 90
ºC
Operating Humidity Range
5 to +95 (non-condensing)
%
Storage Humidity Range
0 to +90 (non-condensing)
%
Hardware Specifications
Symbol
Parameter
Chipset
Qualcomm Atheros QCN9074
WLAN Host Interface
PCI Express 3.0 Interface
System Memory
2Mbit serial I²C bus EEPROM
Standard Operating Voltage
5V
Operating Systems
QSDK
Host Interface
M.2 E Key
Antenna Cable / Port
4 x MMCX Connectors,4T4R
Frequency Range
5.925GHz-7.125GHz
Data Rates for WALN
6GHz, max 23dBm per chain, up to 4949Mbps
Channel Spectrum Widths for WLAN
Support 20/40/80/160MHz at 6GHz
Modulation Techniques
OFDMA: BPSK, QPSK, DBPSK, DQPSK,16-QAM, 64-QAM, 256-QAM,1024-QAM, 4096-QAM
Temperature Range
Operating: -20°C to 70°C, Storage: -40°C to 90°C
Humidity
Operating: 5% to 95% (non-condensing), Storage: Max. 90% (non-condensing)
Certification
TBD
Power Consumption
TBD
Reference Design
PN02.7
Dimensions (WxHxD)
57mm x 63mm x 6mm
Features
■ Qualcomm Atheros QCN9074
■ 6GHz, max 23dBm per chain, up to 4949Mbps
■ Single Band 6GHz 4x4 WiFi 6E (802.11ax)
■ 4 spatial streams (4SS)
■ M.2 E Key Interface
■ PCI Express 3.0 Interface
2. DR-AP-6018-S-A
Absolute Maximum Rating
Parameter
Rating
Unit
Supply Voltage
24V~48V(DC Jack)
V
Operating Temperature Range
-40 to +70
ºC
Storage Temperature Range
-45 to +105
ºC
Operating Humidity Range
5 to +95 (non-condensing)
%
Hardware Specifications
Symbol
Parameter
CPU
Qualcomm-Atheros IPQ6010
CPU Frequency
Quad-core ARM 64 bit A53 @1.8 GHz processor
System Memory
1GB (2x 512MB) DDR3L 16-bit interface with 32-bit memory bus design
Ethernet Port
1 x 1Gbps Ethernet Ports & POE 1x 1Gbps Ethernet Ports
NGFF Slot
M.2 (NGFF) “E Key” Socket with MiniPCIe 3.0(For WiFi Module)
SD Card Slot
1x SD Card Slot(Option)
USB /header
1x USB 3.0 Port(Option)
POE
24V~48V passive POE/Active POE(Suport 802.3bt)
DC Jack
24V~48V power supply
LED header
2.0 pitch pin header
Serial Port
1x Serial Port 4 Pin Connector
Wireless
On-board 2x2 2.4GHz MU-MIMO OFDMA 802.11b/g/n/ax, max 23dBm per chain
On-board 2x2 5GHz MU-MIMO OFDMA 802.11a/n/ac/ax, max 20dBm per chain
4 x MMCX Connectors
Nor Flash
8MB
Nand Flash
256MB
DDR
256MB~512MB
Dimension
133mm x 128mm x 44mm
Description
DR-AP6018-S-A is a 2x2 2.4G&5G high power Radio AP Router which including 1x DR6018-S (IPQ6010) Board;2 x 2.4G&5G dipole Antennas; 1 x PSU(DC power or PoE);
1 x Enclosure.
Dipole antenna
■ 2 x 2.4G&5G Antenna
■ 5dBi 2.4GHz/5Ghz
■ SMA Plug interface
■ Plastic rod of black
■ RoHS compliance
Enclosure
■ Dimension: 133x 128 x 44 mm
■ Aluminum alloy material
■ Two Version:
DR-AP6018-S-AB (color black)
DR-AP6018-S-AO (color orange)
■ Support Wally DR6018-S
